Thông tin chi tiết
- Image Sensor1/1.8″ progressive scan CMOS
- Max. Resolution2688 × 1520
- Min. IlluminationColor: 0.001 Lux @ (F1.2, AGC ON)
- Shutter Time1/25 s to 1/100,000 s
- Slow ShutterSupported
- Day & NightIR cut filter
- Lens
- Focal Length & FOV
4-11 mm/8-32 mm (Optional)
0411:
Horizontal FOV: 114.7° to 41.9°;
Vertical FOV: 59.4° to 23.6°;
Diagonal FOV: 141.5° to 48.1°
0832:
Horizontal FOV: 39.7° to 15.9°;
Vertical FOV: 22.3° to 9.1°;
Diagonal FOV: 45.8° to 18.1°
- FocusAuto
- Iris Type
4-11 mm: Fixed iris;
8-32 mm: DC drive
- ApetureF1.38/F1.63-1.8
- Illuminator
- Built-in Supplement Light RangeUp to 50 m
- IR Wavelength850 nm
- Radar
- Detection Distance20 to 50 m
- Speed Range10 to 100 km/h
- Horizontal Detection Angle± 22°
- Vertical Detection Angle± 10°
- Speed Measurement Accuracy-2 to 2 km/h
- Video
- Main Stream
50 Hz: 25 fps (2688 × 1520, 1920 × 1200, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1200, 1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 25 fps (1920 × 1200, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1200, 1920 × 1080, 1280 × 720)
- Third Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
- Video Compression
H.264 and H.265 encoding
Main stream: H.265/H.264/MJPEG
Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeBaseline profile/Main profile/High profile
- H.265 TypeBaseline profile/Main profile/High profile
- Network
- ProtocolsTCP/IP, HTTP, HTTPS, FTP, DNS, RTP, RTSP, RTCP, NTP, IPv6, UDP
- Simultaneous Live ViewUp to 6 channels
- APIONVIF (PROFILE S, PROFILE G, PROFILE T),ISAPI,SDK,ISUP
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- SecurityPassword protection, HTTPS encryption, digest authentication for HTTP/HTTPS, digest authentication for ONVIF (Version 2.1)
- Network StorageMicro SD/TF card (128 GB), local storage and CVR, NVR, ANPR
- ClientiVMS-8600, Hik-Central
- Web BrowserChrome V61 to Chrome V89, IE9 to IE11
- Image
- Image SettingsRotation mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable via client software or web browser.
- Day/Night SwitchAuto/Scheduled
- Wide Dynamic Range (WDR)140 dB
- Image EnhancementBLC, 3D DNR
