Thông tin chi tiết
- Image Sensor9 MP (1” GMOS)
- Max. Resolution4096 × 2160
- Min. IlluminationColor: 0.001 Lux@(F1.4, AGC ON), B/W: 0.0005 Lux@(F1.4, AGC ON), 0 Lux with IR
- Shutter Time50 us-20000 us
- Day & NightIR cut filter
- Lens
- Lens Type
Varifocal lens, manual adjustment, 11 to 40 mm,
Varifocal lens, motorized lens, 11 to 40 mm
- Focal Length & FOV11 to 40 mm, horizontal FOV 61.8° to 23.5°, vertical FOV 32.4° to 12.2°, diagonal FOV 70.0° to 26.8°
- FocusManual,(AF)Model: Auto
- ApertureF1.6-25,(AF)model: F1.6
- Illuminator
- Built-in Supplement Light TypeIR light
- Light Bead16
- Built-in Supplement Light RangeUp to 40 m
- IR Wavelength850 nm
- External Supplement LightStrobe and flash light
- Radar
- Working Frequency24.05 to 24.25 GHz
- Modulation WaveformFMCW
- Antenna Beam Width35° × 16°
- Detection Distance40 m
- Speed Measuring Range10 to 320 km/h
- Max. Detectable TargetsUp to 32
- Speed Measuring Accuracy±2 km/h
- Coverage LanesUp to 3 lane(s)
- Capture Rate≥ 95%
- Trigger ModeApproaching direction,Leaving direction,Bidrection
- Video
- Main Stream
50 Hz: 50 fps (4096 × 2160, 3840 × 2160, 3392 × 2008, 3072 × 1728, 2688 × 1520, 1920 × 1200, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (4096 × 2160, 3840 × 2160, 3392 × 2008, 3072 × 1728, 2688 × 1520, 1920 × 1200, 1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 50 fps (3392 × 2008, 2688 × 1520, 1920 × 1080, 1280 × 720, 704 × 576)
60 Hz: 30 fps (3392 × 2008, 2688 × 1520, 1920 × 1080, 1280 × 720, 704 × 576)
- Third Stream
50 Hz: 50 fps (1920 × 1080, 1280 × 720, 704 × 576)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 576)
- Video Compression
Main stream: H.265/H.264/MJPEG,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeBaseline profile/Main profile/High profile
- H.265 TypeMain profile
- Network
- ProtocolsTCP/IP,ICMP,HTTP,HTTPS,FTP,DNS,RTP,RTSP,RTCP,NTP,SNMP,IGMP,UDP,IPv4/IPv6,ISUP,ARP,DHCP,802.1X
- Simultaneous Live ViewUp to 6 channels
- APIONVIF (PROFILE S, PROFILE G, PROFILE T),ISAPI,SDK,ISUP
- User/Host
Up to 32 users
3 user levels: administrator, operator and user
- SecurityPassword protection,Complicated password,HTTPS encryption,802.1X authentication (EAP-PEAP, EAP-LEAP, EAP-MD5),Basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for ONVIF,Control timeout settings
- Network StorageMicro SD/TF card (512 GB),Local storage,CVR,NVR,ANR
- ClientiVMS-4200 (Only for live view and LPR information search),Hik-Central Master,Hik-Central Pro,HikCentral Master Lite
- Web BrowserChrome V61+, IE9 to IE11, Firefox V41+, Edge
- Image
- Image SettingsSaturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser.
- Day/Night SwitchAuto,Schedule,Manual
- SNR60 dB
- Image EnhancementBLC, HLC, 3D DNR
